honeywell Tecton 冷鏈專用移動數據終端

產品說明

產品特點

技術參數

honeywell Tecton 冷鏈專用移動數據終端介紹

霍尼韋爾Texton CS工業級手持式移動數據終端專為嚴酷的冷鏈環境而打造。霍尼韋爾Tecton CS移動數據終端其輕巧，非常適合高強度分揀掃描，且能夠在度寒冷環境中操作，它采用內部加熱系統和屏幕除冰技術以及特制電池組，能夠優化產品操作生命周期和操作員進出冷凍環境的可用性。Tecton冷鏈專用移動數據終端能夠在-30°C的低溫下正常運行。

Tecton 冷鏈專用移動數據終端 Accessories

Batteries

MX7392BATT - Tecton Main Battery, Lithium Ion. It can also be used with MX7.

MX7396BATTERY - Tecton CS Main Battery, Lithium Ion, Low-temperature. It can also be used with MX7CS.

MX7394BATT - Tecton Main Battery, Lithium Ion, 10-pack. It can also be used with MX7

MX7398BATTERY - Tecton CS Main Battery, Lithium Ion, Low-temperature, 10-pack. It can also be used with MX7CS

Chargers

MX7390CHARGER - 4 Unit Main Battery Charger with power supply and US power cord. US power cord included.

MX7391CHARGER - 4 Unit Main Battery Charger with power supply, C14 type power cord required. AC power cord is not included. A country specific power cord must be purchased separately. When this product is shipped internationally it may be necessary to order and ship the appropriate internation AC power cable at the same time. This product has a C14 style AC power connector. Choose the proper C14 style cable from the international cables in the power cable section.

Handles

MX7402HANDLE - MX7 padded handle with rubber overmold and two finger trigger, includes wrist strap, for use with MX7 and MX7CS. Rated down to -22 deg F (-30 deg C.)

MX7504WRSTSTRAP - MX7 Wrist Strap 10 Pack

Cases

MX7404CASE - MX7 Voice Application case with belt. MX7 with rubber protective boot will not fit in this case.

MX7408CASE - Carry case for MX7 without handle with Gearkeeper retractor. MX7 with rubber protective boot will not fit in this case.

MX7411CASE - Carry case for MX7 with handle. For use with retractor MX7412BELT. MX7 with rubber protective boot will not fit in this case.

MX7412BELT - Gearkeeper retractor with belt for use with MX7411CASE.

MX7A413CASENHDL - Carry case for MX7 with no handle, includes shoulder strap. MX7 with rubber protective boot will not fit in this case. Large, tethered stylus can be ordered separately for this case, 9000A510STYLUS.

MX7A414CASEHDL - Carry case for MX7 with handle, includes shoulder strap. MX7 with rubber protective boot will not fit in this case. Large, tethered stylus can be ordered separately for this case, 9000A510STYLUS.

honeywell Tecton 冷鏈專用移動數據終端特性

更佳的用戶體驗：大按鍵非常適合戴手套操作；明亮的帶加熱顯示屏能適應從室外卸載區到黑暗的冷凍庫場地轉移，不會受冷凝結霜現象影響正常操作

方位應用：視用戶需求既可以作手持使用，也可以作車載使用。配備55或32鍵帶背光燈的鍵盤，結合ToughTalk專有技術，創造性的結合了先進的音頻回路和降噪技術

堅固耐用：符合IP65工業等級，能夠承受從1.8m至水泥地面的多次墜落，且擁有適用冷藏環境的配置，降低了企業的總體擁有成本

Adaptus? 影像技術：能夠識讀一維和二維條碼，采集數碼圖像，并支持電子簽名采集，為工作人員實現一機多用

快速可靠的無線連接：為室內外應用提供面的無線覆蓋，可以隨時獲取重要數據

高枕無憂的服務選項：為設備投資提供長達五年的售后方位無煩擾保護，降低了總體擁有成本

Remote MasterMind? 遠程設備管理軟件：提供方便的設備管理方案，可遠程管理和追蹤已投入設備，降低總體擁有成本

honeywell Tecton 冷鏈專用移動數據終端技術參數

物理/環境參數
體積：223mmL*86mmW*50mm
重量：595g
操作溫度：-30 ℃到50℃
存儲溫度：-20 ℃到70℃
相對濕度：5%-100%（無凝結）
抗摔強度：1.5m高度到水泥地面的多次墜落（含手柄）；1.8m含橡膠套附件（含/不含手柄）
環境密封等級：受到立認證的防潮和防微塵顆粒等級達到IP65標準
ESD：±8kV接觸放電；±15kV空氣放電

系統構造
CPU：PXA320 806MHz處理器
操作系統：Microsoft windows Mobile6.5，Microsoft Windows CE6.0
內存：256MB Flash，256MB SDRAM
顯示屏：3.5英寸QVGA（240*320），TFT彩色LCD帶加熱器
觸控板：工業級觸控板，電阻觸摸式，支持指觸式和觸摸筆
鍵盤：帶背光燈的55鍵字母數字式和32鍵數字轉字母式
音頻：支持外接耳麥、經認證語音識別應用、揚聲器可調節音量控制
I/O接口：RS-232/USB2.0客戶端/語音輸出/充電連接
存儲擴展：用戶可接觸的SD存儲卡槽，支持1GB或4GB SD存儲卡
電池：鋰電池，7.4V，2200mAh
電池壽命：8小時以上電池工作時間（每10秒通過WLAN或藍牙掃描和發送數據一次）
掃描頭：5300 SR影像頭-帶高清激光瞄準器，SE955E激光引擎，SE955i短景深激光引擎，SE1524ER長景深激光引擎
解碼能力：解讀標準1D和2D條碼體系
開發環境：用戶Windwos Embedded系統的霍尼韋爾SDK開發套件
可選軟件：Wavelink TE，RFTerm（TN5250,TN3270,VT220），AppLock工具控制用戶應用權限及不希望改變的配置，Wavelink Avalanche和LXE Express Config兼容，Stay-Linked Ready
